LARISA — NEW MINIATURE OPTICS FAMILY FROM LEDiL

Small in size but high in efficiency. This versatile lens family is based on a convenient 10 x 10 mm footprint. Uniform size makes clustering easy and installation clips help mounting on to the PCB. LARISA family features a comprehensive range of beam angles from real spot to extra wide, including oval. It has very good efficiency considering it’s size, up to 90 %. LARISA family comprehensively supports different LEDs from all of the largest LED manufacturers, including Cree, Nichia, Philips Lumileds and Osram.

FEATURES

  • Complete range of beam patterns; Real Spot, Medium, Wide, Extra Wide and Oval.
  • Easy mounting with installation clips for 0.8 mm and 1.6 mm PCB thicknesses
  • Diameter 9.9 x 9.9 mm, height 7.5 mm
  • Holder is made of PC and lens precision-moulded from optical grade PMMA
  • RoHS compliant and UL94 HB rated material with high operating temperature


TYPICAL APPLICATIONS



RELATED PRODUCTS

LARISA FAMILY
